Mance .
★ CPS每个叶轮均经过静态和动态平衡，平衡等级达到G2.5，确保库克的产品可以长期按期运行。
Every wheel is statically and dynamically balanced to the level of G2.5. This would help the cook fan running quietly after long time.
◆ 结构紧凑
Compact profile
★ 风机的蜗壳中心高降低，节省风管安装空间。
The low center height of scroll leaves more space for duct installation.
★ 风机皮带长度缩短，延长皮带使用寿命。
Belt length reduce and belt life extended.
★ 风机整体结构紧凑，重量更轻，节约机房占地,
Fan size reduced and has low weight, expensive mechanical room space saved.
◆ 蜗壳可旋转，现场可调节出风方向
Housing can be rotated at jobsite
风机蜗壳有八等分螺栓固定，现场可以调节出风方向。
Scroll is fixed by 8 bolts, draft direction can be rotated at jobsite.
◆ 天然防爆
Natural explosion resistant
铝制叶轮，铝制进风口，SPARK 防爆。
Aluminum wheel & inlet , spark B resistant construction.
◆ 适合室外安装
Suitable for outdoor installation
★ 风机采用完全防护，运转部件与雨、雪隔离。
Avoid sunshine, rain, snow directly impact on running parts.
★ 整体防雨罩可以有效保护驱动部分。
Optional weather-hood can protect the whole drive.
◆ 检修方便
★ 蜗壳自带检修门，可清除叶轮及蜗壳内污垢.
The access door made in the casing is helpful to clean the inner of the fan.
★ 电机两侧设有检修门
Access doors are available on both sides of motor chamber.
◆ 齐全的配件：
Complete accessories
★ 防雨罩
室外安装时可选配防雨罩，有效防止雨雪与阳光、雨、雪接触。
When fan mounted outdoor , Weather-hood shall be selected to prevent motor, pulley & bearing from sunshine, rain and snow.
★ 排污孔
置于风机蜗壳底部，及时排除液态污物。
Located on the bottom of scroll to discharge contaminated substance .
★ 轴承延长润滑油管（限皮带传动结构）Extended lube lines（Apply to belt drive only)
将轴承的润滑油嘴延长到风机外部，避免润滑时拆掉轴承护罩，减小维护工作量。
Use extended lube lines for easy maintenance, avoiding removing bearing cover while oiling .
★ 减振器 Vibration isolators
可选配吊装后座地安装型，材质为丁氰橡胶或弹簧。
Vibration isolators can be hung or floor-mounted ,material can be neoprene or spring type.
★ 进出口软连接Inlet/Outlet Flexible Duct Connector
风机与风管之间的柔性连接装置，可实现不同管径、不同中心高度的系统对接，同时避免风机振动传至整个系统。
Flexible Duct Connectors provide a flexible connection between the fan and the attached ductwork. This reduces the transmission of noise and vibration to the ductwork as well as allowing for slight misalignment.
